1. System characteristics
1. Connect 1-4 camera video signals, adjustable brightness, saturation, contrast, chromaticity and sharpness
2. High resolution: NTSC standard: 720X480, 60Hz.PAL standard: 720X576, 50Hz
3. Diverse display modes: four-screen, two-screen, single-screen, and picture-in-picture automatically switch display mode.
4. High-performance screen freezing function: flashing screen capture
5. High-performance image electronic amplification function”The enlargement area can be selected
6. Diverse character stacking information.Camera title, real-time time and alarm date/video loss/move detection information.
7. Playback can be made in four-screen and single-screen modes
8. Provide a variety of input methods:
9. Alarm input, video loss detection, motion detection can record 60 event reports, and a built-in buzzer. Video standard | PAL: 50 games/second NTSC: 60 games/second | Solution | PAL: 720X576 NTSC: 720X480 | Video input | 1.0Vp-p75 BNC | Video input | 1.0Vp-p75 input | Video output | 1.0Vp-p75 output | Alarm method | Video loss alarm, external trigger method, mobile detection alarm | Video output method | Full screen, electron enlarge, quadruple, painting in painting, automatic switching | Operating Voltage | DC12V/1A | Ambient temperature | -30 ℃ -60 ℃ |
 |
