| Sort by color: | Zhongke Micro -chip solution; UBX7020 chip solution; UBX8030 chip solution; MTK3333 chip solution; Zhongke Micro -chip Program+Beidou Afood; UBX7020 chip solution+Beidou antenna; UBX8030 chip solution+Beidou antenna; MTK3333 chip solution+Beidou antenna; |
| Model: | SR1723; |
| Brand: | Xinghewei; |
| Place of origin: | Chinese mainland; |
| Applicable scene: | Car, driving record; |
| Size: | 17x23x8mm; |
| Cold start capture time: | 29 seconds; |
| Speed accuracy: | 0.05m/s; |
| Module type: | GPS+Beidou; |
| Hot start capture time: | 1 second; |
| Positioning accuracy: | 3m; |
SR1723Z1 Product specification book and test software download address: http://www.sragps.com/web/down.html Purchase modules and deliver 5 DuPont lines for free, with a length of 20cm, and a random color line sequence.As shown in the picture:
Zhongke Micro 6558D chip solution: (30 yuan) Product shipment default: GPS+Beidou dual-mode positioning, FLASH version, 3.3V or 5V power supply, TTL level output, 9600 baud rate, 1HZ output, NMEA-0183 protocol output. ---------------------------------------------------------------------------------- U7 chip solution: (35 yuan) Product shipment by default: GPS single-mode positioning, built-in FLASH, 3.3V or 5V power supply, TTL level output, 9600 baud rate, 1Hz output, NMEA-0183 protocol output. ---------------------------------------------------------------------------------- U8 chip solution: (40 yuan) Product shipment by default: GPS+GLONASS dual-mode positioning, built-in FLASH, 3.3V or 5V power supply, ---------------------------------------------------------------------------------- MTK3333 chip solution: (40 yuan) Product shipment default: GPS+Beidou dual-mode positioning, FLASH version, 3.3V or 5V power supply, TTL level output, 9600 baud rate, 1HZ output, NMEA-0183 protocol output. ----------------------------------------------------------------------------------
Users can set it freely: 2. Output statement: (GGA, GSA, GSV, RMC, VTG, GLL) can be set up arbitrarily. 3. Data refresh rate: 1Hz-10Hz refresh rate (can be set 1-10 times per second). 4. You can freely set the PPS second pulse (such as let the PPS light flash every 3 seconds, etc., can be used for synchronization of indicator lights) With Flash, this product will not recover after setting the parameters.
Product size: 28*28*8.5mm
|
