Product Features/Characteristic | • One receiver can support four transmitters to work simultaneously, with an effective distance of up to 50 meters• VHF frequency band, selected anti-interference frequency point combination, transmitters are used simultaneously without interference• It has anti-sound feedback howling function, which can effectively reduce the generation of howling• with independent and hybridØ 6.3mm audio output socket, can be connected to mixer and karaoke amplifier• adopt independent packaging to meet the needs of different occasions• The frequency of the transmitter and the corresponding receiver is distinguished by different colors, which is clear at a glance and easy to operate. |
Scope/Range | • Handheld microphone: suitable for karaoke singing, program hosting, outdoor activities and other occasions Waist-mounted transmitter: suitable for program interviews, radio applications, outdoor activities and other occasions Conference microphone: suitable for small conferences, conference hosting, speeches and other occasions |
Technical Parameters/Parameter | • mute control: lock the news• frequency offset:±18kHz• Frequency response: 80Hz-15kHz• frequency stability:±0.005%• signal-to-noise ratio: >70dB• Distortion: <0.5% (1kHz)• Number of channels: four channels• Sensitivity: -80dBm• usage distance: effective distance 50 meters• Harmonic interference ratio:≥50dB• illusion interference ratio:≥80dB• Receiver power supply: DC 12V-500mA• transmitter power supply: 9V battery (TC-TD) AA1.5V x 2 battery (TC-TL) AA1.5V x 2 battery (TC-TH)• transmit power: <10mA• Frequency range: Orange: 268.9MHz Blue: 240.9MHz Red: 250.3MHz Green: 221.3MHz• output method: independent and hybrid automatic selection |
Standard configuration/Configuration | Host standard configuration:• 1 receiver• 1 audio cable• 1 power adapter• 2 corner codes• 1 instruction manual
|
