Central oxygen supply 5L suction bottle, negative pressure bottle, suction device, purification room suction system

Ⅰ Product Name:Negative pressure suction bottle, suction system, split suction device.
·Product Category: Medical Devices/Other Devices
·Product name: Negative pressure suction device
· Purpose: suitable for drainage of craniocerebral, chest cavity, abdomen, limbs, and gynecological surgery; it can also be used for gastrointestinal decompression and drainage of excessive fluid in patients; it can also be used for suction and drainage of sputum and fluid in general anesthesia, tracheotomy, coma, and critically ill patients.
·· The product name "Negative Pressure Attraction Bottle (Product Name: Negative Pressure Attraction Device)" is made of non-toxic polymer material. The inner liner and the bottle body can be separated, the bottle body can be reused, and the inner liner is used for one-time use.

The attraction bottle is a medical auxiliary device, specifically a suction bottle, used to suck out the dirty liquid in the patient's body.The suction bottle includes a bottle body 1 and a bottle cap 2. There is an opening at the bottom of the bottle body 1 and a piston 3 is installed at the opening.The suction bottle of this open structure is easy to clean, saves time and effort, and is connected to the sewer pipe and does not cause pollution; the suction bottle of this structure can be used repeatedly, which is economical and practical.
[Product Effect] It is mainly used in the attraction system of medical centers, and is used for medical units to absorb pus, blood, sputum and secretions, etc., mainly working under negative pressure.[Product Specifications] 1L, 2L.2.5L, 3L, 5L [Product Introduction] Used for the aspiration of dirty liquid in the patient's body.The suction bottle includes the bottle body and the bottle cap. There is an opening at the bottom of the bottle body, and a piston is installed at the opening.The suction bottle of this open structure is easy to clean, saves time and effort, and is connected to the sewer pipe and does not cause pollution; the suction bottle of this structure can be used repeatedly, which is economical and practical.

Negative pressure suction system (with various plugs):

The negative pressure regulating valve is equipped with the respiratory system of the medical center, and is used for the medical unit to absorb pus, blood, phlegm and secretions.

The main parameters:

1. The working pressure is 0﹋-0.075Mpa (adjustable).

2. Flow rate 0~30L/min (adjustable).

3. When the liquid is suctioned to the calibration capacity, it should be able to automatically seal the suction port and stop the suction.

▲Negative pressure suction system functions:

The suction device is only connected to the negative pressure suction terminal.Various plugs can be connected according to different requirements

Used for: medical equipment belts, equipment walls, towers and other gas supply terminals

Used gas: Negative pressure suction

It is equipped with an overflow safety valve to prevent inhaled dirt from sucking into the negative pressure regulator or into the negative pressure pipeline system.

There are several specifications of 1L, 2L, 3L and 5L, among which 3L and 5L have mobile cars

Plugs are optional, national standard, American standard, German standard, British standard, and other domestic models of plugs.Manufacturer store, quality assurance, complete certificates

Negative pressure suction bottle + cap + pipe + negative pressure gauge valve = four-piece set

You can issue a ticket according to the customer's request
