Golden Langcat narrow belt Internet dial -up 56K modem fax fax Modem serial hard cat support dedicated line mode

Product information

Code 45751425560
Status: New
In stock: 99999 PCs
Approx weight: 0 kg
Sales volume for 30 days: 1
Price per 1 piece :
168.00 $19.17 $
Local delivery:
0.00 $
Quantity: + -
Minimal lot:
Total:
19.17 $
Add to cart

Add to favorites

Vendor info

Name: flowerweb
Shop name: 翔硕电子科技
Shipping estimate: 5
Goods valuation: 5
Service evaluation: 5
Add vendor to favourites
Rating:
Product name: Golden waves; KN-JT560;
Brand: Golden waves;
Golden wave model: KN-JT560;
Original description


 Industrial modem.For work bags, Support dedicated line mode



Full-duplex voice data industrial fax MODEM, first choice for 2003 and 2008R2 servers
This product is suitable for EASTFAX multi-user, large number of fax mass sending when EASTFAX is turned off, incoming call management and call center, etc.Industrial-grade MODEM has more stable performance, and uses CONEXANT chip with voice function, and supports dual-standard caller IDs for FSK and DTMF.In EASTFAX, CONEXANT can solve the problem that ordinary voice MODEM cannot send signal faxes when ringing and ringing. It is more successful than other chips to send faxes and has better stability.

Chip: Conexant
Caller ID: Supports dual-standard caller IDs for FSK and DTMF
Voice prompt: Support voice prompt function
Full duplex voice: Support, you can connect the headset to MODEM to make calls via computer
Telephone interface: two telephone ports LINE and PHONE
Type: Desktop MODEM
Installation method: external
Interface type: General RS-232 standard interface
Transmission rate: 56K
Data protocol: ITU-TV.34, V.32 bis, V.32, V.22 bis, V.22, V.23 and
V.21; Bell 212A and 103
Fax protocol: V17, V29, V27ter and V21 Channel2 fax protocol,
Fax speed: 14400bps, supports 33.6kbps high-speed fax
Connection rate: 115200---300bps
Dialing method: audio, pulse
Data Error Correction: V.42 LAPM and MNP2-4
Working mode: Full and half-duplex modes
Data compression: V.42 bis and MNP5
Instruction system: EIA/TIA578 Class 1&Class2, compatible with Hays At instruction set
Flow control method: software (XON/XOFF) or hardware (RTS/CTS) flow control
System support: DOS, Win9/5/98/Me/NT, Win2000, Win2003, Win2008R2, WinXP, WIN7, Linux
Line output impedance: average 600±10%(&Lyga;)
Operating environment: DOS/WIN32/WIN95/WIN98/WIN2K/WINXP/WIN7
Product features: Use aluminum alloy profile with high hardness shell, pure industrial extreme design.Super anti-interference ability.
Input voltage: AC9V;±DC12V
Total power:<2W
Use environment: working temperature -20℃~65℃ Relative humidity: 10%~90%
Protection circuit: Double lightning protection circuit design (using internationally renowned brands of lightning protection devices) use large quantities of optoelectronic coupling devices
Structural dimensions: 120MM&times;66MM&times;27MM

Only imported chips are used in industrial modems. They are stable and durable. They are suitable for dial-up connections in various industrial occasions. They have voice duplex functions and are the best choice for EASTFAX multi-user fax software.

&nbsp;

The latest design plan, hands-free phone call, answering phone, high-speed office efficiency!!!Telecom, China Unicom, and mobile manual service desks in the United States/Germany/Japan, Taiwan, mainland China, etc. are all using this product!

You can send and receive faxes, unplug the number in places without broadband, and unplug the remote host.

Connect to special platforms such as taxation, finance, and social security, with comprehensive functions and stable performance!

&nbsp;

Large quantities of goods arrive, welcome to wholesale!

Serial voice data fax MODEM, EASTFAX official designated dedicated MODEM, perfectly supported WIN7 system

forEASTFAX fax software is stable to send and receive faxes, and uses ROCKWELL with voice functionChip, supports FSK caller ID.In EASTFAX, ROCKWELL can solve the problem that ordinary voice MODEM cannot send signal faxes when ringing and ringing. It is more successful than other chips to send faxes and has better stability.

Features:
Fully support V9.2 and V9.0 protocol standards, with high-speed data transmission, fax and voice transmission functions, and supports plug-and-play (plug) of WIN/XP/2000/9X/ME/NT&Play) function makes it very easy to install and use.

Fully support V9.2 and V9.0 protocol standards, with high-speed data transmission, fax and voice transmission functions, and supports plug-and-play (plug) of WIN/XP/2000/9X/ME/NT&Play) function makes it very easy to install and use.● Fax ITU-T V.17 fax 14.4-7.2K bps, ITU-T V.29 V.27ter fax9.6-2.4k bps Class/Fax
● V 8.0 video conferencing function
● Caller ID function
● Support international standard HAYES AT instruction set&nbsp;&nbsp;

&nbsp;

Data transmission protocol: V90, K56flex (56K), V.34, V.32 bis, V.32, V.22bis, V.22/212A, V.21/103, 56Kbps
Dialing method: audio and pulse method
Error correction protocol: MNP2-4, V.42
Compression protocol: MNP5, V.42 bis
Flow control: Software (Xon/Xoff) or Hardware (RTS/CTS)
Reception sensitivity:-40&plusmn;2dbm
Transmission level:-10&plusmn;1db
Compatible with operating systems: WIN98, WINME, WINNT, WIN2000
Support transmission rate: 56K bps/33.6K bps
System hardware requirements: microcomputers with serial ports above 486
Working humidity: 20%-90%
Storage humidity: 10%--90%v

Jinlang KN-JT568C, 56K external Modem adopts a simple plug-and-play installation method, a graphic interface, supports multiple operating systems, supports Hayes AT instruction set, supports V8.0 video conferencing function, supports international standard AT instruction set, and adopts TOPIC chip, which has higher quality, is not easy to disconnect, and has a dual lightning protection design, is easy to install and has superior performance.It is worth mentioning that the Jinlang KN-JT560 uses an old-fashioned interface, not the popular RJ45 interface.

&nbsp;

&nbsp;

&nbsp;&nbsp;&nbsp;

&nbsp;

&nbsp;&nbsp;&nbsp;&nbsp;The following is a method for installing MODEM drivers in WIN7 system, as shown in the figure below:

&nbsp;

&nbsp;


&nbsp;

Open My Computer - Properties - Device Manager, select any one of them right-click, and select&ldquo;Scan and detect hardware changes

move&rdquo;, at this time, the MODEM will appear as shown in the figure, and the driver will automatically recognize and install it.

XP system: Open My Computer - Properties - Hardware - Device Manager, select any one and right-click, and select&ldquo; Scan

Detect hardware changes&rdquo;, you can complete the driver installation.

&nbsp;

&nbsp;

1. Download and install the EASTFAX fax software:

Download address: http://www.eastfax.com/cn/down/default.aspx

&nbsp;

2. After installation, two icons of EASTFAX server and client will appear on the desktop:



&nbsp;

3, Log in to the server software:


&nbsp;

4, Set MODEM parameters on the server side:

Click Stop Send to Stop Receive-Fax Service-Set MODEM parameters, then click MODEM to automatically detect, when pop-up

The box prompts that a valid modem is detected and then click Start Send and Receive




&nbsp;

5, Create a new user account on the server side:

&nbsp;



6
, set the default fax receiving account on the server side:


&nbsp;

7, client login:


&nbsp;

8, Send fax:


&nbsp;

9. The fax is successfully submitted to the server:

10. Check the server-side fax sending status:

11. Receive fax:

When a fax comes in the server

The received fax is viewed in the client-received fax:
