HD200Monitor is suitable for ChongqingCW200diesel engineReal-time monitoring of parameters such as rotation speed, lubricant pressure, cooling water temperature, lubricant temperature, and booster air pressure; parameter over limit alarm or shutdown; fuel leakage alarm function; remote monitoring of parameters can be realized; automatic diesel engine uptimeAccumulated; parameters can be modified online according to user requirements.
The main function
l1Road speed measurement display
l2Road pressure measurement display
l2Road temperature measurement display
l1Road fuel leakage alarm function
lLEDShow the operating time of diesel engine
lLEDDisplay diesel engine alarm status
lHave reset, time, silence, self -examination, emergency stop, starting function
lPressure zero -automatic zero -adjustment function
lParameter online modification function
lMeasure value online correction function
l10Core remote display interface
The main technical parameters
lOperating Voltage:DC24V±30%
lOperating temperature:-20OC~55OC
lMonitor's appearance size:300x200x210mm
lMonitor installation size:160x120mm
lRemote display size:205x165x70mm
lFar -pass display panel open hole size:195x155mm
Related product accessories
lZS-M16x1.5Speed sensor
lYCY-44-M18x1.5Pressure Sensor
lYCT-13-M16x1.5Pressure Sensor
lWDC50-M14x1.5Temperature Sensor
lHD200Signal
lHD200Power starter
lHD200Shutdown line
lYX200Remote display
lYX200Remote transmission cable (10core25rice)
Monitoring instrument number
lC62.15.11.1001
lC62.15.11.1004
